Grizzly G4000 - Manual (Page 48)

G4000 9'' x 19'' Lathe -47-
R RE EF F P PA AR RT T # # D DE ES SC CR RIIP PT TIIO ON N
01 P4000801 SADDLE
02 P4000802 CROSS SLIDE
03 P4000803 GIB
04 P4000804 CROSS SLIDE NUT
05 P4000805 LEAD SCREW
06 P4000806 BRACKET
07 PSB24M CAP SCREW M5-0.8 x 16mm
08 P4000808 PLATE
09 P4000809 RIVET 2 X 5
10 P4000810 GRADUATED DIAL
11 P4000811 KEY 3X13
12 P4000812 SPRING
13 P4000731 HANDWHEEL
14 P4000814 SPECIAL HEX NUT
15 PSS17M SET SCREW M8-1.25 x 6mm
16 P4000734 HANDLE
17 P4000817 SLIDE BLOCK
18 P4000818 BUSHING
19 PFH02M FLAT HD SCR M6-1.0 x
12mm
20
PSS04M SET SCREW M6-1.0 x 12mm
21 P4000821 PIN
22 PSS22M SET SCREW M4-0.7 x 12mm
23 PN04M HEX NUT M4-0.7
24 P4000824 APRON TENSION BAR
25 PW03M FLAT WASHER M6
26 PSB01M CAP SCREW M6-1.0 x 16mm
27 P4000827 CLIP
28 PSS25M SET SCREW M6-1.0 x 20mm
29 PN01M HEX NUT M6-1.0
30 PSB06M CAP SCREW M6-1.0 x 25mm
31 P4000831 WAY WIPER
32 P4000832 WIPER CLAMP
33 PS17M PHLP HD SCR M4-0.7 x 6mm
34 P4000834 WAY COVER
35 P4000835 COVER MOUNT
36 P4000836 OIL PORT
37 PSB13M CAP SCR M8-1.25 x 30mm
38 PSB06M CAP SCR M6-1.0 x 25mm
39 P1550633 SPECIAL BOLT
40 P4000840 CHIP GUARD
