Grizzly G4000 - Manual (Page 50)

G4000 9'' x 19'' Lathe -49-
R RE EF F P PA AR RT T # # D DE ES SC CR RIIP PT TIIO ON N
01 P4000901 COMPOUND SLIDE
02 P4000902 SWIVEL BASE
03 P4000903 GIB
04 P4000904 CLAMPING RING
05 P4000905 GRADUATED DIAL
06 P4000906 SLIDE NUT
07 P4000907 ADJUSTING SCREW
08 P4000908 TOOL POST STUD
09 P4000909 T-SCREW
10 P4000910 PIN
11 P4000911 TOOL POST NUT
12 PB26M HEX BOLT M8-1.25 x 30mm
13 PSB50M CAP SCREW M5-0.8 x 10mm
14 PFH02M FLAT HD SCR M6-1.0 x 12mm
15 PSS23M SET SCREW M4-0.7 x 10mm
16 PN04M HEX NUT M4-0.7
17 PN01M HEX NUT M6-1.0
18 P4000918 LOCK PIN 3 X 8
19 P4000919 LOCK PIN 3 X 14
20 P4000920 TOOL CLAMP
21 PW01M FLAT WASHER 8mm
22 P4000922 SPRING
23 P4000923 LEAD SCREW
24 P4000924 LEAD SCREW MOUNT
25 P4000925 GRADUATED DIAL
26 P4000926 HANDWHEEL
27 P4000927 HANDLE
28 PK39M KEY 3 x 3 x 10mm
29 P4000929 CURSOR
30 P4000930 THREADED COLLAR
31 PSS17M SET SCREW M8-1.25 x 6mm
32 P4000932 LOCK PIN 3X12
33 P4000933 PLATE
34 P4000934 PIN
35 P4000935 TOOL REST
38 PSB13M CAP SCREW M8-1.25 x 30mm
39 P4000939 LOCK HANDLE
40 P4000940 LOCK NUT
