-4-
G0604 6" X 56" Jointer
Design Type: .................................................................................................... Floor Model
Overall Dimensions:
Table Size .............................................................................................. 6" W x 55 1 ⁄
2
" L
Height (from floor to table) ....................................................................................32 1 ⁄
2
"
Table Length .........................................................................................................55 1 ⁄
2
"
Table Width ................................................................................................................6"
Shipping Weight ............................................................................................... 347 lbs.
Net Weight ....................................................................................................... 320 lbs.
1
st Box Size ................................................................................... 29"L x 18"W x 28"H
2 nd Box Size ................................................................................... 62"L x 21"W x 14"H
Stand Footprint ...................................................................................... 27"W x 20 1 ⁄
2
"D
Cutterhead ..........................................................................................................4-Knife
Cutterhead Diameter ..................................................................................................3"
Cutterhead Knife Size ............................................................................... 6" x 3 ⁄
4
" x 1 ⁄
8
"
Capacities:
Maximum Depth of Cut (per pass) ............................................................................ 1 ⁄
8
"
Maximum Width of Cut ...............................................................................................6"
Cutterhead Speed ........................................................................................ 4850 RPM
Cuts Per Minute ................................................................................................. 19,400
Construction:
Tables ................................................................................ Precision Ground Cast Iron
Fence Assembly ............................................................................................. Cast Iron
Body Assembly ............................................................................................... Cast Iron
Stand ................................................................................................... Preformed Steel
Guard ............................................................................................................. Aluminum
Bearings ................................................................................. Shielded and Lubricated
Motor:
Type ............................................................................TEFC Capacitor Start Induction
Horsepower ........................................................................................................... 1 HP
Phase ⁄ Voltage ............................................................................ Single-Phase / 110V
Amps .......................................................................................................................13A
Cycle ⁄ RPM ................................................................................. 60 Hertz / 3450 RPM
Power Transfer .............................................................................................. Belt Drive
Bearings ................................................................................. Shielded and Lubricated
Sound Rating .......................................................................................................80 dB
Features:
...................................................................................Parallelogram Table Adjustment
...........................................................................................Top Mount Switch Controls
...................................................................................... Fence Stops at 45°, 90°, 135°
.................................................................................................... Included 4" Dust Port
....................................................................................................Included Push Blocks
............................................................................................. Included Knife Setting Jig
Specifications, while deemed accurate, are not guaranteed.
MODEL G0604 6" X 56" Jointer
Customer Service #: (570) 546-9663 • To Order Call: (800) 523-4777 • Fax #: (800) 438-5901
MACHINE DATA
SHEET
Machine Data Sheet
