Grizzly G0604 - Manual (Page 13)

G0604 6" X 56" Jointer
-11-
After all the parts have been removed from the
two boxes, you should have the following items:
Jointer Box: (Figure 2) Qty
A. Jointer Assembly ........................................ 1
B. Carriage ...................................................... 1
C. Fence ......................................................... 1
D. Extension Table .......................................... 1
E. Push Blocks ................................................ 2
F. Cutterhead Guard ....................................... 1
G. Tool Hardware Bag
— Hex Wrenches 2.5, 4, 5, 6, 8mm ...1 Each
—Open-end Wrench 8/10mm .................... 1
H. Knife Setting Jig (not shown) ..................... 1
Stand Box: (Figure 3) Qty
I. Stand Assembly w/Motor ........................... 1
J. Pedestal Switch .......................................... 1
K. Dust Port .................................................... 1
L. Wheel Assembly ......................................... 1
M. Belt Guard .................................................. 1
N. V-Belt .......................................................... 1
Assembly Fasteners Qty
• Hex Bolt M8-1.25 x 50 (Wheel/Stand) ....... 1
• Flat Washer 8mm (Wheel/Stand) ............... 1
• Hex Bolts M10-1.5 x 55 (Wheel/Stand) ...... 2
• Flat Washers 10mm (Wheel/Stand) ........... 2
• Hex Nuts M10-1.5 (Wheel/Stand) .............. 2
• Cap Screws M8-1.25 x 25 (Jointer/Stand) . 4
• Lock Washers 8mm (Jointer/Stand) ........... 4
• Flange Bolts M6-1 x 12 (Belt Guard) ......... 2
• Hex Nuts 6mm (Belt Guard) ....................... 2
• Flat Washers 6mm (Belt Guard) ................ 2
• Cap Screws M8-1.25 x 30 (Fence) ............ 2
• Cap Screws M8-1.25 x 20 (Pedestal) ........ 2
• Lock Washers 8mm (Pedestal) .................. 2
• Flat Washers 8mm (Pedestal) .................... 2
• Phillips Screws M5-.8 x 16 (Dust Port) ...... 4
• Flat Washers 5mm (Dust Port) .................. 4
• Cap Screws M10-1.5 x 30 (Carriage) ........ 2
• Flat Washers 10mm (Carriage) .................. 2
• Cap Screws M6-1 x 20 (Ext Table) ............ 2
Figure 2. Box 1 inventory contents.
Figure 3. Box 2 inventory contents.
A
B C
F
K
J
Inventory
D
E
G
L
M
N
I
In the event that any nonproprietary parts are
missing (e.g. a nut or a washer), we would be
glad to replace them, or for the sake of expedi-
ency, replacements can be obtained at your local
hardware store.
NOTICE
Some assembly fasteners may arrive pre-
installed on the machine. Check the mount-
ing locations on the machine before assum-
ing that any items from the inventory list are
missing.
