Grizzly G1019 User Manual
Page 43
G1019 14'' Bandsaw
-41-
REF
PART #
DESCRIPTION
REF
PART #
DESCRIPTION
123 P1019123
FRAME ARM COVER
128 P1019128
CIRCLE CUTTING ATT.
130 P1019130
MITER GAUGE
133 P1019133
DUST CHUTE
134 PB05
SCREW
135 PW06
SNAP RING R34
136 P1019136
DOOR HINGE UPPER
137 P1019137
DOOR HINGE LOWER
138 P1019138
BRUSH
139 P1019139
BRUSH BRACKET
140 P1019140
SELFTAP SCRW 10-24X
3
⁄
8
"
141 P1019141
FLAT WASHER
142 P1019142
FRAME ARM COVER, LWR
144 P1019144
HEX NUT
5
⁄
16
"-18
145 P1019145
BLADE GUARD LOWER
147 P1019147
STUD, DOOR
148 P1019148
CLIP HEAD
149 P1019149
SWITCH PLATE
150 P1019149
HEX SCREW
1
⁄
4
"-20 X
1
⁄
4
"
151 P1019151
FLAT WASHER
1
⁄
4
"
152 P1019152
SCALE
153 P1019153
POINTER
154 P1019154
SCREW
155 P1019155
FLAT WASHER
3
⁄
16
"
156 P1019156
SETSCREW
3
⁄
16
"-20 X
3
⁄
8
"
157 P1019157
BALL STUD
158
PWRCRDRECP
POWER CORD W/RECP
159
PWRCRDPLUG
POWER CORD W/PLUG
160 PB05
HEX HEAD BOLT
161 PW03
FLAT WASHER
162 PS07
PHILLIPS HEAD SCREW
163 P1019163
GUIDE SHAFT KNOB
164 PS06
PHLPHD SCREW 10-24 X
3
⁄
8
"
165 PS01
PHLPHD SCREW 10-24 X
1
⁄
2
"
166 PWN01
WING NUT 10-24
83
PW07
FLAT WASHER
5
⁄
16
''
84
P1019084
MOTOR
86
PN02
HEX NUT
5
⁄
16
''-18
87
PSS01M
SETSCREW M6-1.0X10mm
88
P1019088
MOTOR PULLEY
90
P1019090A SWITCH
90D P1019090D SWITCH KEY
91
PWRCRD110
POWER CORD
92
PVA51
V-BELT A-51
93
P1019093
PULLEY COVER
96
PW03
FLAT WASHER #10
98
P1019098
TOP PANEL
99
P1019099
RIGHT ANGLE BRACE
100 P1019100
DOUBLE BEND BRACE
101 P1019101
MOTOR MOUNT PLATE
102 P1019102
REAR PANEL
103 P1019103
STAND BRACE
105 P1019105
FRONT PANEL
106 P1019106
MOTOR SUPPORT PLATE
107 PB07
HEX BOLT
5
⁄
16
''-18 X
3
⁄
4
''
108 PW07
FLAT WASHER
5
⁄
16
''
109 PN02
HEX NUT
5
⁄
16
''-18
110 PS02
PHLP HD SCR
1
⁄
4
''-20 X
3
⁄
4
''
111 PW06
FLAT WASHER
1
⁄
4
''
112 PN05
HEX NUT
1
⁄
4
''-20
113 P1019113
RUBBER FOOT
114 P1019114
FENCE
115 P1019115
FENCE GUIDE BLOCK
116 PB02M
HEX BOLT M6-1.0X12mm
117 P1019117
KNOB
118 P1019118A GUIDE RAIL
119 P1019119
MOUNT BRACKET
120 PSB01M
CAP SCREW M6-1.0X16MM
121 PLW01
LOCK WASHER
5
⁄
16
''
122 P1019122
STAND COVER
