-40- G1019 14'' Bandsaw
REF PART # DESCRIPTION REF PART # DESCRIPTION
01 P1019001A UPPER FRAME ARM
04 P1019004A GUIDE POST
05 P1019005 GUIDE SUPPORT BRACKET
05A P1019005A GUIDE BLOCK HOLDER
06
P1019006 KNOB SCREW
07 P1019007 UPPER SPACING SLEEVE
07A PR01M SNAP RING 10mm
08 P1019008 BLADE GUARD
09 P6200 BEARING 6200-2RS
10 PSS01M SETSCREW M6-1.0X10mm
11 P1019011 BLADE GUIDE BLOCK
12 P1019012 TENSION KNOB
15 P1019015 SPRING
16 P1019016 SLIDING BRACKET
17 P1019017 SQUARE NUT 3 ⁄
8
''-16
18 P1019018 ADJUSTMENT KNOB
19 P1019019 SHAFT HINGE
21 P1019021 STEEL PIN
22 P1019022 UPPER WHEEL SHAFT
23 P6202 BEARING 6202-2RS
24 P1019024 UPPER WHEEL
25 P1019025 TIRE
26 PN01 HEX NUT 1 ⁄
2
''-20
27 P1019027 STUD
28 P1019028A UPPER GUARD, INSIDE
29 P1019029A UPPER GUARD, OUTER
30 P1019030A KNOB
31 P1019031 SET PIN
32 PB01 HEX BOLT 3 ⁄
4
''-10 X 2 1 ⁄
2
''
33 PW13 FLAT WASHER 3 ⁄
4
''
34 P1019034A BASE
35 PN17 HEX NUT 3 ⁄
4
''-10
36 G1169 BLADE
37 P1019037 TABLE INSERT
38 P1019038 TABLE PIN
39 P1019039 TABLE
40 P1019040 SPECIAL HEX BOLT
41 P1019041 TRUNNION CLAMP SHOE
42 P1019042 TRUNNION
43 PW06 FLAT WASHER 1 ⁄
4
''
44 PB02 HEX BOLT 1 ⁄
4
''-20 X 5 ⁄
8
''
45 P1019045 TRUNNION SUPPORT BRKT
46 P1199046 STAR KNOB
47 PB03 HEX BOLT 5 ⁄
16
''-18 X 1''
48 PW07 FLAT WASHER 5 ⁄
16
''
49 PB04 HEX BOLT 5 ⁄
16
''-18 X 3''
52 PN02 HEX NUT 5 ⁄
16
''-18
53 PB05 HEX BOLT 1 ⁄
4
''-20 X 3 ⁄
4
''
54 PW06 FLAT WASHER 1 ⁄
4
''
55 P1019055 LOWER GUIDE SUPPORT
56 PSS01M SETSCREW M6-1.0X10mm
57 P1019057 WASHER
58 P6200 SCREW
60 PSS01M SETSCREW M6-1.0X10mm
61 PK21M KEY 5X5X23
62 PSS01M SETSCREW M6-1.0X10mm
63 P1019063 PULLEY
64 PR09M SNAP RING 20mm
65 P1019065 SHAFT
66 P6204 BEARING 6204-2RS
67 P1019067 LOWER WHEEL
68 PN03 HEX NUT 3 ⁄
4
''-16
69 P1019069A LOWER WHEEL GUARD
70 P1019070 GUARD
71 PB06 HEX BOLT 5 ⁄
16
''-18 X 2''
72 PW07 FLAT WASHER 5 ⁄
16
''
74 PN02 HEX NUT 5 ⁄
16
''-18
75 PCB02 CARR BOLT 5 ⁄
16
''-18 X 5 ⁄
16
''
76 PW07 FLAT WASHER 5 ⁄
16
''
79 PW07 FLAT WASHER 5 ⁄
16
''
81 PK21M KEY
82 PB07 HEX BOLT 5 ⁄
16
''-18 X 3 ⁄
4
''
