Grizzly Vertical Milling Machines G0728 User Manual
Page 55
Model G0728–31 (Mfg. Since 11/11)
-53-
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
401
PS68M
PHLP HD SCR M6-1 X 10
436
P6204ZZ
BALL BEARING 6204ZZ
403
P0730403
COLUMN
437
P0730437
VERTICAL LEADSCREW
405
PCAP68M
CAP SCREW M6-1 X 8
438
P0730438
LEADSCREW BASE
406
P0728406
KNEE GIB
439
P0730439
BASE SIDE COVER
407
P0728407
GIB ADJUSTMENT SCREW
440
P0730440
PLUG
409
P0730409
KNEE
441
P0730441
BASE
410
P0730410
CHIP GUARD
442
P0730442
COVER
411
PS12M
PHLP HD SCR M3-.5 X 6
444
P0728444
LIMIT TRACK
412
P0730412
KNEE LOCKING SCREW
444-1 P0730444-1
SPLASH PAN
415
P0728415
SPANNER NUT
445
PB01M
HEX BOLT M10-1.5 X 30
416
P0730416
SPANNER NUT WASHER 20MM
446
P0730446
LIMIT STOP
417
P0728417
BEVEL GEAR
447
PN02M
HEX NUT M10-1.5
418
P6004ZZ
BALL BEARING 6004ZZ
448
PB29M
HEX BOLT M6-1 X 30
419
P0730419
VERTICAL CRANK HOUSING
449
PB72
HEX BOLT 1/2-13 X 2
420
PCAP01M
CAP SCREW M6-1 X 16
450
PLW07
LOCK WASHER 1/2
421
P0730421
WOODRUFF KEY 5 X 20
452
P0728452
SPINDLE SWITCH KEDU ZH-HC-3
422
P0728422
VERTICAL CRANK SHAFT
454
P0728454
COLUMN ACCESS PANEL
423
PR09M
EXT RETAINING RING 20MM
455
PS03M
PHLP HD SCR M6-1 X 8
424
P0728424
CLUTCH
456
P0730456
POWER CORD 14G 3W 72" 5-15
425
PSS03M
SET SCREW M6-1 X 8
457
P0728457
STRAIGHT LT STRAIN RELIEF 3/8 PT
426
P0728426
LOCKING THUMB SCREW 5-.8 X 12
459
P0730459
MOTOR CORD 14G 5W 36"
427
P0728427
GRADUATED DIAL
460
PS20M
PHLP HD SCR M5-.8 X 15
428
P0728428
CRANK HANDLE ARM
461
P0730461
ONE SHOT OILER ASSEMBLY
429
PR07M
EXT RETAINING RING 18MM
462
P0730462
ELBOW ADAPTER
430
P0730301
HANDLE 3/8-16 X 1/2
463
PS60M
PHLP HD SCR M5-.8 X 30
431
P0728141
HANDWHEEL
464
P0730464
T-ADAPTER
432
P0728432
GRADUATED DIAL
465
PN06M
HEX NUT M5-.8
433
P51104
THRUST BEARING 51104
466
P0730466
OIL TUBING 4MM X 100MM
434
P0728434
BEARING HOUSING
467
P0730467
OIL TUBING 4MM X 340MM
435
P0731606
CROSS FEED LEADSCREW
G0730 & G0731 Knee & base parts List
