5-1
5. INPUT/OUTPUT DATA
Input and output data are shown in the table below.
Note: This radar accepts position data fixed by WGS-84 geodetic datum only. Set the
datum to WGS-84 on the EPFS (GPS, etc.) connected to this radar. If other type of datum is
input, the error message "DATUM" appears and the AIS feature is inoperative. Baud rate for
the serial input is automatically set to 4800, 9600, 19200 or 38400 as appropriate.
Input
Data Specifications Contents Remarks
synchro or step GC-10 required
AD-10 format External AD-100
Heading signal
IEC 61162-2**
AD-10 and
IEC 61162 are switched by
menu setting.
Speed signal IEC 61162-1
Navaid data IEC 61162-1 Position, course,
speed, LORAN-C TD,
waypoint, route, time,
wind data, current
data, depth,
temperature, roll,
pitch, ROT
For IMO spec, IEC-61162-1
Edition 2 is required.
External radar
signal
Heading,
Bearing, Trigger,
Video
No STC control Operate as remote display
Contact closure Input from alarm system Alarm ACK input
IEC61162-1 ACK Input from alarm system
Track Control unit RS-422 Option
Output
Radar system data RS-232C RSD, OSD, TLL, For PC plotter
TT data* IEC 61162-1 TTD, TTM For ECDIS
ALARM data IEC 61162-1 ALR For ALARM system
Remote display
signal
HD, BP Trigger,
Video
2 ports
External LCD
monitor signal
DVI Same as main display
unit
2 systems in total
External CRT
monitor signal
R, G, B, H, V Same as main display
unit
Option
Contact closure Output to alarm system
by using photo-relay
4 systems, Output contents
are selected by menu.
Alarm signal
IEC 61162-1 ALR Output to alarm system
*The output sentence, mode and baud rate can be set at the TT Preset menu.
**Data cycle should be input with more than 40 Hz (HSC) or 20 Hz (normal speed).
