FARGO electronic Quatro ID Card Printer User Manual
Page 3
Table of Contents
Chapter 1: Getting Started
I.
Choosing a Good Location ..........................................................1
II.
About Moisture Condensation....................................................1
III.
Unpacking and Inspection ...........................................................2
Chapter 2: Powering Up the Printer
I.
Applying Power ............................................................................3
II.
Identifying the Printer Features ..................................................5
Chapter 3: Ribbons and Cards
I. About
Ribbons ...............................................................................6
II.
Loading Ribbon into the Printer .................................................7
III.
About Cards .................................................................................10
IV.
Loading Cards into the Printer .................................................10
V.
Printing a Self Test.......................................................................12
Chapter 4: Using the Quatro ID Card Printer
I.
Connecting the Printer to your Computer ..............................13
II.
Installing the Windows Printer Driver ....................................14
III.
Installing the 32-Bit Print Spooler for Windows 95/98 .........16
IV.
Setting up the Windows Printer Driver...................................18
V.
Printing a Card ............................................................................26
Chapter 5: Maintenance
I.
Supplies Required .......................................................................27
II.
Standard Printhead Cleaning ....................................................28
III.
Expanded Printhead Cleaning ..................................................29
IV.
Cleaning the PrinterÕs Case .......................................................29
V.
Cleaning the Inside of the Printer.............................................30
VI.
Clearing a Card Jam....................................................................30
VII.
Clearing a Ribbon Jam................................................................31
VIII. Cleaning the Card Feed Rollers ................................................31
IX.
Cleaning the Drive Roller ..........................................................33
X.
Maintaining the Cleaning Rollers .............................................33
Chapter 6: Troubleshooting
..........................................................................35
Chapter 7: Technical Specifications
............................................................41
iii
Quatro/510323 v3 1/8/99 10:48 AM Page iii
