40
Table A-2 Pinouts of Flat Cable Connector B
*:The evaluation MCU signal name of table A-2 should keep in mind that actual signal
names differ for every kind for a "temporary name".
Connector
pin number
Evaluation
MCU
signal name
(temporary
name)*
Evaluation MCU
pin number
Connector
pin number
Evaluation
MCU
signal name
(temporary
name)*
Evaluation MCU
pin number
A1 GND
−
B1 GND
−
A2
− −
B2 PG5 50
A3 PG4 4 B3 PG3 315
A4 PG2 208 B4 PG1 98
A5 PG0 153 B5 PF3 182
A6 PF2(DVcc) 127 B6 PF1 239
A7 GND
−
B7 PF0 31
A8 PE7 293 B8 PE6 183
A9 PE5 78 B9 PE4 128
A10 PE3 184 B10 PE2 32
A11 PE1 240 B11 GND
−
A12 PE0 129 B12 PD7 79
A13 PD6 294 B13 PD5 185
A14 PD4 130 B14 PD3(DVcc) 241
A15 GND
−
B15 PG6 97
A16 PD2 80 B16 PD1 295
A17 Vcc_B
−
B17 PD0 344
A18 PB7 298 B18 PB6 132
A19 PB5 189 B19 GND
−
A20 PB4 246 B20 PB3 348
A21 PB2 299 B21 PB1 133
A22 PB0 81 B22 VCC3IO 33
A23 GND
−
B23 PA7 247
A24 PA6 190 B24 PA5 34
A25 PA4 134 B25 PA3 82
A26 Vcc_B
−
B26 X0 29
A27 X1 291 B27 GND
−
A28 P17(D15) 258 B28 P16(D14) 146
A29 P15(D13) 203 B29 P14(D12) 259
A30 P13(D11) 93 B30 P12(D10) 147
A31 GND
−
B31 P11(D9) 204
A32 P10(D8) 312 B32 P07(D7) 260
A33 P06(D6) 94 B33 P05(D5) 45
A34 P04(D4) 205 B34 P03(D3) 148
A35 P02(D2) 1 B35 GND
−
A36 Vcc_B
−
B36 P01(D1) 95
A37 P00(D0) 46 B37 INITX 126
A38 MOD0 292 B38 MOD1 30
A39 GND
−
B39 MOD2 77
A40 PI7 206 B40 PI6 261
A41 PI5 47 B41 PI4 313
A42 PI3 2 B42 PI2 149
A43 PI1 150 B43 GND
−
A44 PI0 262 B44 PH7 48
A45 PH6 96 B45 PH5 151
A46 PH4 207 B46 PH3 49
A47 GND
−
B47 PH2 3
A48 PH1 263 B48 Vcc_B
−
A49 PH0 264 B49
− −
A50 GND
−
B50 GND
−
APPENDIX User Interface Specifications
