33
5.5 Power-on/Shutdown Procedures
■ Power-on Procedure
To turn the power on, finish making all the required connections and follow the procedure in Figure
5.5-1.
To turn on the emulator, press the power switch on the back of the emulator. The power switch re-
mains depressed.
Check the position of the power switch with the hardware manual for the emulator.
Note : When turning on the individual components of your system, follow the power-on procedure specified in
the manual.
Once you have turned the adapter on, do not carry it or apply shock or vibration to it.
Figure 5.5-1 Power-on Procedure
Finish connecting all the components of your entire system, then turn them on in the order: host machine ->
emulator -> user system.
Shut down your system by turning off the components in the order: user system -> emulator -> host machine.
The power supply of a host computer is switched on.
The power supply of an emulator is switched on.
“ S OFTUNE
Workbench” is started.
“Emulator Debugger” is started.
A dialog display is checked (see Figure 5.5-2).
The power supply of a user system is switched on.
"OK" is checked by dialog display (see Figure 5.5-2).
POWER LED lights up
Chapter 5 Usage
