Appendix user interface specifications – FUJITSU MB2198-130 User Manual
Page 45
38
Figure A-1 Pin Numbers of Flat Cable Connectors A and B
CN1
A50
A
A1
B50
B1
CN2
A50
B
A1
B50
B1
TOP VIEW
B50
A
B1
A50
A1
B50
B
B1
A50
A1
TOP VIEW
Flat cable connector
Flat cable connector
Adapter board
Header or a user system
(connector is mounted
in the back)
(connector is mounted
in the surface)
APPENDIX User Interface Specifications
