2.3 General Specifications
■ General Specifications
Table 2.3-1 lists the general specifications of the adapter.
Table 2.3-1 General Specifications
* : For the internal power and I/O power supplied to each evaluation MCU, refer to the power sup-
ply specifications of the evaluation MCU. For each type of supplied power, refer to the "Eval-
uation MCU Hardware Manual" or Please ask, when unknown.
Note : Operating the device outside the range of any general specification may cause the device to malfunc-
tion. Use the device in the ranges of its general specifications.
Table 2.3-1 lists the general specifications of the adapter.
Item Specification
Name DSU-FR emulator PGA-401P adapter type 2
Part number MB2198-130
Power supplies
Evaluation MCU: Internal power supply * 0 V to +5.5 V (UVcc)
Evaluation MCU: I/O power supply * 0 V to +5.5 V (UVcc)
Adapter board power supply +3.3 V (Supplied from emulator)
Internal operating
frequency of MCU
34 MHz max.
Operating tempera-
ture
5
°
C to 35
°
C
Operating humidity 20% to 80% (No condensation allowed)
Dimensions
205 (W)
×
110 (D)
×
30 (H) mm (Including the IC socket and connector di-
mensions)
Weight 173 g
