APPENDIX
AP-3
Alarm Volume (0, 1, 2, 3, 4, 5, 6, 7)
Bottom alarm Alarm depth (0-10000; 0m)
Alarm zone (1-10000: 1m)
Fish alarm Alarm depth (Fish: 0-10000; 0m)
Alarm depth
(Bottom fish: 0.0-200.0; 0.0m)
Alarm zone (Fish: 1-10000; 1m)
Alarm zone (Bottom fish: 1.0-200.0; 1.0m)
Temp alarm Temp limit
(Within range, Out of range: -5.0-35.0; 20.0
°
C)
Alarm zone
(Within range, Out of range: 0.1-30.0; 1.0
°
C)
V-temp alarm Temp limit
(Within range, Out of range: -5.0-35.0; 20.0
°
C)
Alarm zone
(Within range, Out of range: 0.1-30.0; 1.0
°
C)
Record Recording setting Recording location
Recording time (1-24; 24(hr))
Required free space (512-32767; 1024(MB))
Record info Data view
Disk space info ( Time, Size)
4 6
7 8
5
System Output TLL ( OFF, ON)
Bottom discrimination ( OFF, ON)
NMEA version (Version 1.5, Version 2.0, Version 3.0)
Compensation Stabilization (OFF, ON)
Heave (OFF, ON)
Sound veolocity (1400-1600; 1500m/s)
Draft (-6.0-60.0; 0.0m)
Roll offset (-10.0-10.0; 0.0 deg)
Pitch offset (-10.0-10.0; 0.0 deg)
Motion sensor (SC, Internal sensor)
SC-TD in longitudinal dir (-100.0-100.0; 0m)
SC-TD in port/stdb dir (-100.0-100.0; 0m)
SC-TD in up/down dir (-100.0-100.0; 0m)
Internal sensor in bow dir (0-360; 0 deg)
Temp Temp input (CIF, NMEA)
Temp adjust (-20.0 to 20.0, 0)
Net Input data (CIF, NMEA)
V-temp graph Horizontal axis (Min) (-5.0-35.0; -5.0
°
(C))
Horizontal axis (Max) (-5.0-35.0; -35.0
°
(C))
(Measurement)
(Unit)
Fish gain (-12.0-12.0; 0)
Measurement threshold (2-20; 4(cm))
Measuring area (Manual, All, Specific range, Bottom trace)
Manual area (Vertical) (10-100; 10(%))
Manual area (Horizontal) (10-100; 10(%))
Bottom trace area (2m, 5m, 10m, 20m, 50m, 100m, 200m)
Calibration value (-30.0-30.0; 0(db))
Unit (TS, L(cm), L(inch))
