APPENDIX
AP-4
7 8
Color Day/Night (Day, Night)
Hue ( Standard, Mono, USER1, USER2)
Marker line (Change color.)
VRM (Change color.)
Temp graph (Change color.)
Bottom discrimination (Change color of Hardness and Flatness graph lines.)
Net (Change color of Net marks 1-6.)
Pane (Change color of window border.)
Unit Depth ( m, ft, fa, hiro, P/B)
Temperature (
°
C,
°
F)
Speed ( kt, km/h, mph)
Bearing ( TRUE, Magnetic)
Communication Network IP address ( 192. 168. 2. 3)
Port (5001-30000; 10000)
NMEA Port (COM1, NMEA1, NMEA2, CIF)
Baud rate
( 4800 Bps, 9600 Bps, 19200 Bps, 38400 Bps)
Bit rate (7 Bit, 8 Bit)
Stop bit ( 1 Bit, 1.5 Bit, 2 Bit)
Parity bit ( None, Even, Odd)
SC Port (COM1, NMEA1, NMEA2, CIF)
Baud rate
(4800 bps, 9600 bps, 19200 bps, 38400 bps)
Bit rate (7 Bit, 8 Bit)
Stop bit ( 1 Bit, 1.5 Bit, 2 Bit)
Parity bit ( None, Even, Odd)
CIF Port (COM1, NMEA1, NMEA2, CIF)
Baud rate
(600 Bps, 1200 bps, 2400 bps, 4800 bps)
Bit rate ( 7bit, 8bit)
Stop bit (1 Bit, 1.5 Bit, 2 Bit)
Parity bit (None, Even, Odd)
Date (Year/Month/Day/Hr/Min/Sec)
Test/ Version information
Initialization Target sphere calibration
Default settings
Window Auto arrange
Deep mode
Simul. TX
Marker line
