Ap-2 – Furuno FCV-30 User Manual
Page 98
APPENDIX
AP-2
Zoom range (2m, 5m,
10m, 20m, 40m)
User setting
Range1 (2-200:
2m)
Range2 (2-200:
5m)
Range3 (2-200:
10m)
Range4 (2-200:
20m)
Range5 (2-200:
40m)
Shift (0-5000;
0m)
Gain (0.0-10.0;
5.0)
TX rate (0-20;
20)
STC (0-10;
0)
TVG curve (10,
20, 30, 40, manual)
Noise threshold (-30 - +30,
0)
Clutter curve (
Standard, Straight, OFF)
Clutter (
0, 1, 2, 3, 4, 5, 6, 7)
Color resolution ( OFF (0.1-3.0;
1.0)
Picture advance (STOP, 1/8, 1/4, 1/2,
1/1, 2/1, 4/1, 8/1, SYNC)
LIne interpolation (
OFF, ON)
Noise limiter (
OFF, NL1, NL2, NL3)
Signal level (0-14;
0)
Echo smoothing (
OFF, 1, 2, 3, 4)
Ping setting (
Internal, External)
Bottom search (
ON, OFF)
User TVG setting (0-40;
20)
Multi-beam TX frequency (Low,
Standard, High)
TX pulse length (
Standard, Long)
TX power (Level1, Level2, Level3, Level4,
Level5)
Depth/distance (Depth,
Distance)
Simul. TX start Rng (100-5000;
1000)
Status
Display item (
ADVANCE, SHIFT, ALARM, GAIN, TIMER, TEMP,
L/L, SPEED, COURSE, ROLL, PITCH, HEAVE, P/B, TD)
Window (
Opaque, Transparent)
Display (
Window, Fixed at bottom)
Font size (Small,
Standard, Large)
Draft indication (
OFF, ON)
Fish size
Fish size histogram
Horizontal axis scale (10, 20, 30, 40,
50, 60, 70, 80 90, 100(%))
Vertical axis area (1, 2,
3, 4, 5, 6)
Vertical zoom rate (
100, 200, 400(%))
Vertical zoom area )7, 6, 5,
4, 3, 2, 1)
White mark (
OFF, ON)
White mark area (Min) (2-1000m;
20cm)
White mark area (Max) (2-1000m;
20cm)
Peak (
OFF, ON)
Target graph
Radius scale (2, 3,
4, 5)
4
5
1
2
3
6
(Display)
