General
Status Extended
Status
Description
0x7FF
0x02 n/a Connection Manager resources are unavailable to handle service request
0x03 n/a
Invalid connection number specified by the Get_Connection_Data service. This is
also returned by the Search_Connection_Data service if the specified connection is
not found
0x04
Zero Based
Word Offset
Segment Type in path is invalid. The Extended Status shall be the word offset (0
based) to the word in the path where the error occurred. The offset starts at the
first word after the path size. This error shall not be returned if an error occurs
when parsing the Connection Path.
0x05
Zero Based
Word Offset
Destination in path is invalid. The Extended Status shall be the word offset (0
based) to the word in the path where the error occurred. The offset starts at the
first word after the path size. This error shall not be returned if an error occurs
when parsing the Connection Path.
0x07 n/a
Connection has been lost. This is used by the Get/Set Services when they are made
through a connection
0x08 n/a Connection Manager does not support the requested Service
0x09
Index to
Element
Error in Data Segment. Extended Status shall be index to where the error was
encountered in the Data Segment. The Configuration Revision Number if present
in the Data Segment shall always be index 1. If the error occurs with the Get/Set
Services, then the extended status indicates the attribute number that failed.
0x0C Optional
Service cannot be performed while Object is in current state. The 1st word of
Extended Status may optionally contain the object’s current state.
0x10 Optional
Service cannot be performed while Device is in current state. The 1st word of
Extended Status may optionally contain the device’s current state.
0x11 n/a
Response data too large. This is used by the get services to indicate the amount of
data requested was too large to fit into the response buffer.
0x13 n/a Not enough data was received.
0x14 Attribute Id Attribute specified in FIND service is not supported by Connection Manager
0x15 n/a Too much data was received.
0x25 0x0114
Either the Vendor Id or the Product Code in the key segment did not match the
device. Used if the Key Segment was contained in the path.
0x25 0x0115
Product Type in the key segment did not match the device. Used if the Key
Segment was contained in the path.
0x25 0x0116
Major or Minor Revision information in the key segment did not match the device.
Used if the Key Segment was contained in the path.
0x026 n/a Invalid path size
NOTE:
The word “n/a” in the Extended Status Column is used to signify that there is no additional Extended
Status which is required to be returned for the particular General Status Code.
The word “optional” in the Extended Status Column is used to signify that if Extended Status information
is used, then the first word of that extended status is already defined
