FS-8704-14 EtherNet/IP Manual Page 27 of 31
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
Appendix D. Reference
Appendix D.1. Error Messages
Message Description
"EIP:#01 FYI. %d out of %d data
elements will be stored"
"MD=%s,
data_type=0x%04X,
raw bytes=%d"
If the number of data elements exceeds the Map Descriptor length only the
number of data elements corresponding to the Map Descriptor will be stored.
This message will print once per Map Descriptor.
Appendix D.2. Classes and Attributes Supported
EtherNet/IP is an object orientated protocol. The Object Oriented structure therefore allows for classes, instances,
attributes and services. The ‘data types’ listed below are to be considered as the objects supported in the
protocol. Each of these has attributes that have been supported to differing degrees.
FieldServer Data Type Description (or Device Data Type)
Identity – Class Code 0x01
Attributes Supported:
One instance supported (0x01)
Attributes List:
Vendor ID
Device Type
Product Code
Device Revision
Status
Serial Number
Device Description (text) Services Supported:
Get_Attribute_All;
Get_Attribute_Single
Message Router – Class Code
0x02
Attributes Supported:
One instance supported (0x01)
Attribute List:
Max Connections Services Supported:
Get_Attribute_Single
Assembly – Class Code 0x04
Attributes Supported:
Class Instance Support (0x00)
Class Attributes: 0x02 (Max Instance)
Two instances supported (0x0100 and 0x0101)
Attribute List:
Member List
Not Supported
Data Services Supported:
Get_Attribute_Single
Connection Manager – Class
Code 0x06 Forward Open Service
Forward Close Service
