FS-8704-14 EtherNet/IP Manual Page 28 of 31
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
FieldServer Data Type Description (or Device Data Type)
Register – Class Code 0x07
Attributes Supported:
Class Instance Support (0x00)
Class Attributes: 0x02 (Max Instance)
Two instances supported (0x01 and 0x02)
Attribute List:
Status Flag
Direction (read/write)
Size of Data (bits) Services Supported:
Get_Attribute_Single
Discrete Input Point – Class Code
0x08
No visible interface currently
Discrete Output Point – Class
Code 0x09
No visible interface currently
Analog Input Point – Class Code
0x0A
Attributes Supported:
Class Instance Support (0x00)
Class Attributes: 0x02 (Max Instance)
Two instances supported (0x01 and 0x02)
Attribute List:
Number of Attributes
Not Supported
Analog value (UINT16)
not supported
Vendor ID Services Supported:
Get_Attribute_Single
Analog Output Point – Class Code
0x0B
Attributes Supported:
Class Instance Support (0x00)
Class Attributes: 0x02 (Max Instance)
Two instances supported (0x01 and 0x02)
Attribute List:
Number of Attributes
not supported
Analog value (UINT16)
not supported
Vendor ID Services Supported:
Set_Attribute_Single;
Get_Attribute_Single
TCP/IP Interface Object – Class
Code 0xF5
Attributes Supported:
One instance supported (0x01)
Attribute List:
Status
Configuration Capability
Configuration Control
Physical Link Object
Interface Configuration
Host Name Services Supported:
Get_Attribute_Single
