FS-8704-14 EtherNet/IP Manual Page 11 of 31
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
5.3.6 Map Descriptor Example 1: Unconnected Messages
// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name , Scan_Interval , Data_Array_Name , Data_Array_Offset , Function , EIP_Con_Typ , Node_Name , EIP_Class , Address , EIP_Attribute , EIP_Service , Length
CMD_PRO_03 , 0s , DA_AI_01 , 0 , Rdbc , Unconnected , EIP_01 , 10 , 1 , 3 , Get_Attrib , 1
CMD_PRO_02 , 0s , DA_AI_01 , 1 , Rdbc , Unconnected , EIP_01 , 10 , , 2 , 3 , Get_Attrib , 1
5.3.7 Map Descriptor Example 2: Data Table Messages
// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name , Scan_Interval , Data_Array_Name , Data_Array_Offset , EIP_Con_Typ , Node_Name , Function , EIP_Service , EIP_Path , EIP_Tag_Name , Length
Cmd_Pro_09 , 0s , DA_AI_05 , 0 , Explicit , EIP_01 , Rdbc , Data_Table_Read , 1 1 , analog_in_3 , 2
Cmd_Pro_10 , 0s , DA_AI_06 , 0 , Explicit , EIP_01 , Rdbc , Data_Table_Read , 1 1 , analog_in_4 , 2
5.3.8 Map Descriptor Example 3: PCCC Messages
// Client Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset, , Function , EIP_Con_Typ , Node_Name , EIP_Service , EIP_Path , File_Type File_Number , Address , Length
CMD_01 , DA_F_01 , 0, , Rdbc , Explicit , EIP_01 , Exec_PCCC , 1 0 , F 8, , 30 , 10
