FS-8704-14 EtherNet/IP Manual Page 15 of 31
FieldServer Technologies 1991 Tarob Court Milpitas, California 95035 USA Web: www.fieldserver.com
Tel: (408) 262 2299 Fax: (408) 262 2269 Toll Free: (888) 509 1970 email: [email protected]
6.3.5 Map Descriptor Example 1: Unconnected Messages
// Server Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , Node_Name , EIP_Class , Address , EIP_Attribute , EIP_Service , Length
SMD_PRO_01
, DA_AI_01 , 0 , Passive , EIP_01 , 10 , 1 , 3 , Get_Attrib , 1
SMD_PRO_02 , DA_AI_01 , 1 , Passive , EIP_01 , 10 , 2 , 3 , Get_Attrib , 1
6.3.6 Map Descriptor Example 2: Data Table Messages
// Server Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Node_Name , Function , EIP_Service EIP_Tag_Name , Length
SMD_PRO_09 , DA_AI_05 , 0 , EIP_01 , Passive , Data_Table_Read , Analog_in_3 , 2
SMD_PRO_10 , DA_AI_06 , 0 , EIP_01 , Passive , Data_Table_Read , Analog_in_4 , 2
6.3.7 Map Descriptor Example 3: PCCC Messages
// Server Side Map Descriptors
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , EIP_Con_Typ , Node_Name , EIP_Service , File_Type , File_Number , Address , Length
SRV_AI_01
, DA_F_01 , 0 , Passive , Explicit , EIP_01 , Exec_PCCC , F , 8 , 30 , 20
