Example: Consider a situation where a customer defines a type in RSlogix SSS_SINT3 with 3 members of each type SINT.
SSS_SINT3
SINT room1_temp
SINT room2_temp
SINT room3_temp
Now he has his own type SSS_SINT3 and he can define tags: TAG_3ROOM_TEMPS of type SSS_SINT3
// Read/write structures
Map_Descriptors
Map_Descriptor_Name , Data_Array_Name , Data_Array_Offset , Function , EIP_CON_TYP , Node_Name , EIP_SERVICE , EIP_Path , EIP_TAG_NAME , EIP_Structure_Handle , Length , Scan_Interval
CMD_Struct_SINT3 , DA_STRUCT_R , 0 , Rdbc , EXPLICIT , EIP_01 , DATA_TABLE_READ , 1 0 , TAG_3ROOM_TEMPS , 59592 , 3 , 1.0s
