2640A/2645A NetDAQ
Users Manual
x
2-28.
Viewing the Instrument Ethernet Address...................................................... 2-41
2-29.
Examples for Viewing the Ethernet Address.................................................. 2-42
2-30.
Preparing for Network Operation ................................................................... 2-44
2-31.
Interconnection Using 10Base2 (Coaxial) Wiring.......................................... 2-46
2-32.
Host Computer/Instrument Direct Connection ............................................... 2-47
2-33.
Interconnection Using 10BaseT (Twisted-Pair) Wiring................................. 2-49
3-1.
NetDAQ Logger for Windows Main Window ............................................... 3-4
3-2.
Communications Configuration Dialog Box .................................................. 3-5
3-3.
Instrument Configuration Dialog Box ............................................................ 3-16
3-4.
Channels Configuration Dialog Box............................................................... 3-18
3-5.
Configuration Text File .................................................................................. 3-29
6-1.
Replacing the Fuse.......................................................................................... 6-5
6-2.
Performance Test Setup .................................................................................. 6-8
6-3.
2-Wire Connections to 5700A ........................................................................ 6-8
6-4.
4-Wire Connections to the Universal Input Module (Resistor)...................... 6-20
6-5.
4-Wire Connections to the Universal Input Module (5700A) ........................ 6-21
C-1.
Comparison of Common Waveforms ............................................................. C-3
D-1.
385 RTD ......................................................................................................... D-2
D-2.
375 RTD ......................................................................................................... D-3
D-3.
391 RTD ......................................................................................................... D-4
D-4.
392 RTD ......................................................................................................... D-6
H-1.
10BaseT Ethernet Cables................................................................................ H-2
