BX960 S1

Operating Manual

61

SSD drive

8.1.1

Opening the server blade

Ê

Exit all applications and shut down the server blade correctly. If your
operating system has not switched off the server, press the on/off button on
the server blade control panel.

Removing the server blade from the system unit

Figure 8: Removing the server blade

Ê

Push the locking lever (1) up slightly to unlock the release lever (2).

Ê

Swivel the release lever down until it is horizontal.

Ê

Pull the server blade out of the system unit.

/
