FURUNO
FAR-21x7(-BB)/28x7 SERIES
SP-2 E3519S01P-M
3. MONITOR UNIT
1. Screen Raster scan, daylight bright, yellow or green echoes in 32 levels
2. Display
FAR-2107(-BB)
series
FAR-2107
series
FAR-2107
series
FAR-2807
series
Size, model 17-inch color LCD,
MU-170C 19-inch color LCD,
MU-190 20.1-inch color LCD,
MU-201CR 23.1-inch color LCD
FAR-28x7:
MU-231CR, MU-231
Display area
(mm) 338 x 270 376.32 x 301.06 399.36 x 319.49 470.4 x 352.8
Resolution 1280 x 1024
pixels 1280 x 1024
pixels 1280 x 1024
pixels 1600 x 1200 pixels
Effective
radar
diameter 260 mm
(H: 64 kHz;
V: 60 Hz) 290 mm
(H: 64 kHz;
V: 60 Hz) 308 mm
(H: 64 kHz, V: 60
Hz) 340 mm
(H: 75 kHz, V: 60
Hz)
Viewable
range 920 mm 1020 mm 1080 mm 1200 mm
3. Minimum range 22 m
4. Range discrimination 26 m
5. Range scales (nm), ring interval
Range (nm) 0.125 0.25 0.5 0.75 1.5 2 3 4 6 8 12
Ring interval (nm) 0.025 0.05 0.1 0.25 0.25 0.5 0.5 1 1 2 2
No. of rings 5 5 5 3 6 6 6 4 6 4 6
16 24 32 48 72 96 120
4 4 8 8 12 16 20
4 6 4 6 6 6 6
6. Range accuracy 1% of the maximum range of the scale in use or 10 m, whichever
is greater
7. Bearing discrimination 0.98° (XN5A), 2.1° (XN12AF), 1.5° (XN20AF), 1.2° (XN24AF),
2.0° (SN36AF)
8. Bearing accuracy ±1°
9. Presentation mode Head-up, Cursor Gyro, North-up, Course-up, True Motion
(sea or ground stabilization in True Motion)
10. Target tracking (TT) Auto or Manual acquisition: 100 targets in 0.2-24(32) nm
Auto tracking on all acquired targets
Tracking: 5/10 pts on all targets
11. AIS Capacity: 1000 targets, Tracking: 10 pts on all targets
Time of vector: Off/3/1-50 minutes
12. Radar map 20,000 pts in radar mode, 6000 pts on IC card in chart mode
13. Acquisition zone 2 zones
14. Interswitch function Selectable from menu
4. INTERFACE
1. Heading signal input - Synchro signal (20-100 VDC, 20-135 VAC 50/60/400/500 Hz),
- Stepper signal (20-100 V), built-in interface (option) required,
- AD-10 format or IEC 61162-2
2. Speed log IEC 61162-1
3. AIS IEC 61162-2
