APPENDIX
AP-38
Monitor unit MU-201CR (DC specification)
Noise Filter
(AC spec.: LF-205A
DC spec.: MXB-1206-33)
PWR Module RKW-12-13RE
(DC spec.)
(For AC spec, DC-DC Board
03P9359 is used.)
DIV I/F Board
(SCBFNRB-A)
Monitor unit MU-201CR, rear cover removed
Inverter Board
(210PW021-C)
LCD Board
(201PW023-H)
LCD Unit
(NL128102AC31-02)
Monitor unit MU-201CR, inner shield plate removed
Monitor unit MU-190
MFB52A-12HA-001, 26S0028 (Motor fan (FAN1), Wind direction: top-left)
LQ0DDB0094, 26S0048 (Motor fan (FAN4), Wind direction: upward)
ESSIP33A-1C
(AD board)
26P0013
26P0023
OZP-120-12/15-J06
LQ190E1LX51,
26S0027(LCD)
Monitor unit MU-190
