1. RADAR OPERATION
1-79
[CUSTOMIZE•TEST]
1 BACK
2 [DATA BOX]
3 [F1]
4 [F2]
5 [F3]
6 [F4]
7 [OPERATION]
8 [TEST]
[DATA BOX]
1 BACK
3 NAV DATA
OFF/ON
4 ZOOM
OFF/2TIMES/3TIMES
5 ZOOM DISPLAY
STAB
GND/STAB HGD/
STAB NORTH/
TT TRACK
6 TARGET DATA
1BOX/2BOX/3BOX/
LARGE
1.42 Text Window
The text window, displayed at the right 1/4 of the screen, mainly shows nav data,
zoomed target, and tracked target data. You can set up this window as follows:
1. Left-click the MENU box to open the menu.
2. Select 9 [CUSTOMIZE•TEST]
CUSTOMIZE•TEST menu
3. Select 2 [DATA BOX].
DATA BOX menu
4. Select 3 NAV DATA.
5. Select OFF or ON as appropriate.
6. Select 4 ZOOM.
7. Select OFF or zoom magnification factor (2TIMES or 3 TIMES).
8. If you selected a zoom factor at step 7, go to step 9. Otherwise, go to step
11.
9. Select 5 ZOOM DISPLAY.
