(3) Current Requirements and Power Dissipation
Table 1.3 lists the current and power dissipation.
Table 1.3 Current and power dissipation
Typical RMS current (*1) [mA]
+12 V +5 V
Model MPE3043AE MPE3084AE MPE3173AE All Models MPE3043AE MPE3084AE MPE3173AE
Spin up 1800 peak 1800 peak 1800 peak 540
640 peak
21.9 21.9 21.9
Idle (Ready) (*3) 140 140 170 420 3.8 3.8 4.1
R/W (On Track) (*4) 180 180 210 450 4.4 4.4 4.8
Seek (Random) (*5) 270 270 300 450 5.5 5.5 5.9
Standby 7.0 7.0 7.0 185 1.0 1.0 1.0
Sleep 7.0 7.0 7.0 185 1.0 1.0 1.0
*1 Current is typical rms except for spin up.
*2 Power requirements reflect nominal values for +12V and +5V power.
*3 Idle mode is in effect when the drive is not reading, writing, seeking, or executing any commands. A portion of the R/W circuitry is powered
down, the spindle motor is up to speed and the Drive ready condition exists.
*4 R/W mode is defined as 50% read operations and 50% write operations on a single physical track.
*5 Seek mode is defined as continuous random seek operations with minimum controller delay.
Typical Power (*2) [watts] Mode of Operation
