Self test index

Indicates the latest self test log number. If the self test has not been executed, 00h is
displayed.

(29)

SET MAX ADDRESS (F9)

This command allows the maximum address accessible by the user to be set in LBA or CHS mode.
Upon receipt of the command, the device sets the BSY bit and saves the maximum address
specified in the DH, CH, CL and SN registers. Then, it clears BSY and generates an interrupt.

The new address information set by this command is reflected in Words 1, 54, 57, 58, 60 and
61 of IDENTIFY DEVICE information. If an attempt is made to perform a read or write
operation for an address beyond the new address space, an ID Not Found error will result.

When SC register bit 0, VV (Value Volatile), is 1, the value set by this command is held even after
power on and the occurrence of a hard reset. When the VV bit is 0, the value set by this command
becomes invalid when the power is turned on or a hard reset occurs, and the maximum address
returns to the value (default value if not set) most lately set when VV bit = 1.

After power on and the occurrence of a hard reset, the host can issue this command only once
when VV bit = 1. If this command with VV bit = 1 is issued twice or more, any command
following the first time will result in an Aborted Command error.

At command issuance (I/O registers setting contents)

1F7

(CM)

1F6

(DH)

Max head/LBA [MSB]

1F5

(CH)

1F4

(CL)

1F3

(SN)

Max. cylinder [MSB]/Max. LBA

Max. cylinder [LSB]/Max. LBA

Max. sector/Max. LBA [LSB]

1F2

(SC)

1F1

(FR)

At command completion (I/O registers contents to be read)

1F7

(ST)

Status information

1F6
