AN706-00044-1v0-E
5.4.6 Variable window
- Name: variable observation window.
- Function: show the signal value, select signal.
2
1
Figure 5-8: variable observation window
Table 5-5: variable observation function
Name of area Specification
1 Variable value Show the value form hardware
2 Select signal button Into select the signal window
- Notice:
- This window can select compressor contents. System and Fun contents cannot be
selected.
