AN706-00044-1v0-E
Table 5-4: wave observer function
Name of area Description
1 Form name Custom the name of this wave window.
2 Show wave Draw the wave of signal needing to show.
3 Waveform name Shown the waveform name, it’s come from select signal
4 Select signal
Select the signal to show the wave If the button is clicked, the signal
selection window opens. (See Chapter4.4.3)
5 Wave setting
Select waveform; set waveform color; set the X-grid, Y-grid;
waveform up, down, left, right move; and all setting reset.
6 Other function Pause/run and save/load wave data.
7 System current state Show the current state: connect, PFC, compressor, Fan
- Notice:
- This window can select compressor contents. System and Fun contents cannot be
selected.
- Wave save and load function are not prepared.
- How to operate Signal selection window
Please refer the chapter “Example of total operating Procedure”, too
You can select the data to show the waveform.
The selected parameters are defined wave A through wave D in order.
After selecting, the waveforms are shown the window. As a default, each reference lines
are defined as follows;
20
