AN706-00044-1v0-E
If you want to save the setting value, after connecting to the board and setting some
parameters,
(1) Push “saveconfig” button under the window.
(2) Select the saving folder and name the .aip file
(3) Push save button and the configuration file is saved.
If you want to load the configuration file, after connecting to the board,
(1) Push “loadconfig” button under the window.
(2) Select the loaded .aip file
(3) Push open button and the configuration file is loaded.
Saveconfig and Loadconfig button
Some parameters can be set as an over-range value, but the firmware can modify as a
maximum or minimum value automatically.
