2-31
ITEM PART # COMPONENT
1 106-1018SP Flue Assembly, Dual-vat
2 200-0941 Back, Dual-vat Combustion Chamber
3 200-2229 Retainer, Dual-vat Upper Insulation
4 809-0059 Nut, 1/4-20 Flange Hex
5 809-0360 Screw, #8 X 3/8-inch Hex Head
6 809-0362 Screw, #8 X 1 1/4-inch Hex Washer Head Drill Point
7 809-0435 Washer, Steel
8 809-0500 Screw, #10 X 1/2-inch Hex Washer Head 410 SS
9 809-0804 Nut, 1/4-20 Keps Hex
10 810-0476 Spacer, .25-inch X 1.187-inch
11 810-0500 Spacer, .25-inch X .9375-inch
12 826-1072 Burner, Universal Replacement
13 812-0354 Insulation, Dual-vat Lower Rear
14 812-0356 Insulation, Burner Sight Glass
15 816-0577 Insulation, Burner
16 812-0404 Insulation, Left or Right Front Seal
17 812-0458 Insulation, Dual-vat Lower Front
18 812-0688 Insulation, Flue Collector
19 812-0706 Insulation, Upper Burner Rail
20 812-0993 Insulation, Upper Oil Zone
21 812-1029 Insulation, Combustion Chamber Side
22 814-0048SP Glass, Burner Sight
23 816-0057 Gasket, Plenum
24 816-0558 Insulation, Dual-vat Lower Front
25 816-0559 Insulation, Dual-vat Upper Front
26 823-0970 Plenum, Dual-vat
27 823-2822 Side and Rail, Left Dual-vat Combustion Chamber
28 823-2823 Side and Rail, Right Dual-vat Combustion Chamber
29 900-4253 Strip, Fluecap Retainer
30 823-3302 Front, Dual-vat Combustion Chamber
31 823-3303 Retainer, Dual-vat Lower Front Insulation
32 824-0865 Retainer, Left Dual-vat Upper Insulation
33 824-0866 Retainer, Right Dual-vat Upper Insulation
34 900-0914 Retainer, Lower Rear Insulation
35 900-1031 Retainer, Burner Sight Glass
36 900-1049 Retainer, Plenum Gasket
37 900-1515 Brace, Upper Oil Zone Insulation
38 900-4452 Retainer, Combustion Chamber Side Insulation
39 930-0818 Bracket, Flue to Frypot
40 824-0541 Riser, DV Pot Divider W/A
* 910-2474 Pot-to-Pot Gap Clip
* 826-0930 Insulation Kit, Complete Dual-Vat
* 826-0932 Insulation Kit, Burner Dual-Vat
* 823-3327 Frypot, Dual-vat
* 106-1080SP Frypot, Complete Assembly, Natural/Propane
* Not illustrated.
** For rear flush oil return components, see page 2-20.
