2-14
ITEM PART # COMPONENT
1 810-1569 Valve Assembly, 1.25-inch Full-Vat Non-Filter Drain (includes handle)
* 810-1427 Lock Pin Handle for 1.25-inch Valve Assembly
2 806-7915SP Valve Assembly, 1-inch Left Dual-Vat Non-Filter Drain (complete assembly)
3 806-7916SP Valve Assembly, 1-inch Right Dual-Vat Non-Filter Drain (complete assembly)
4 809-0589 Nut, ½-13 2-Way Lock (used on non-filter drain valves)
5 810-1427 Handle w/Lock Pin, Full Vat
6 810-1568 Handle w/Lock Pin, Left Drain Valve Dual Vat
7 810-1567 Handle w/Lock Pin, Right Drain Valve Dual Vat
8 106-3760SP Valve Assembly, 1.25-inch Full-Vat w/Filter Drain (complete assembly)
9 106-5607SP Valve Assembly, 1-inch Left Dual-Vat w/Filter Drain (complete assembly)
10 106-5606SP Valve Assembly, 1-inch Right Dual-Vat w/Filter Drain (complete assembly)
11 816-0135 O-Ring, Drain Valve
12 810-1018 Valve, 1.25-inch Drain
13 806-8137 Bracket Assembly, Drain Safety Switch
14 816-0220 Insulation, Drain Safety Switch
15 807-2103 Microswitch, Lever Activated
16 901-2348 Cover, Drain Safety Switch
17 826-1366 Nut, 4-40 Hex Keps (Pkg. of 25)
18 824-1602 Handle, Full-Vat Drain Valve
19 900-2936 Retainer, Full-Vat Drain Valve Nut
20 809-0540 Nut, ½-13 2-Way Lock
21 816-0639 Grip, Drain Valve Handle
22 200-6496 Support, 3-inch Drain Tube
23 810-1114 Valve, 1-inch Dual-Vat w/Filter Drain
24 809-0196 Washer,
⅜-inch Flat
25 810-1165 Washer, ⅜-inch Teflon
26 900-2934 Retainer, Dual-Vat Drain Valve Nut
27 809-0539 Nut,
⅜-16 2-Way Lock
28 824-1637 Handle, Left Dual-Vat Drain Valve
29 824-1636 Handle, Right Dual-Vat Drain Valve (Must order item 16 and item 30 to fit)
30 106-2671 Bracket Assembly, Dual-Vat Drain Safety Switch
31 810-1338 Valve, 1-Inch Dual-Vat Non-Filter Drain
32 Drain Valve Extension
812-1226SP Full-Vat (1.25-inch)
812-1227 Dual-Vat (1-inch)
