2-9
ITEM PART # COMPONENT
1 Frame, Control Panel
806-4732 Single-Station, Standard (use 106-5016 mfd. After 3.15.06) (use 106-6079 for fallback)
106-3902SP Two-Station, Standard (use 106-5221SP mfd. After 3.15.06)(use 106-6082 for fallback)
106-3903SP Three-Station, Standard (use 106-55018SP mfd. After 3.15.06)(use 106-6086 for fallback)
106-3904SP Four-Station, Standard (use 106-5019 mfd. After 3.15.06)(use 106-6087 for fallback)
106-3905 Five-Station, Standard (use 106-5020 mfd. After 3.15.06)(use 106-6089 for fallback)
2 210-5819 Bezel, Two-Controller
3 210-6698 Bezel, Three-Controller
4 210-5046 Bezel, One-Controller
5 210-5623 Bezel, Blank
6 Brace, Cabinet Top
200-5498 Single Fryer
900-7730 Two-Station
900-9430 Three-Station
900-9318 Four-Station
200-5474 Five-Station
7 200-5478 Divider, Cabinet
8 200-6614 Post, Cabinet Front
9 200-2235 Bracket, Component Box Support
10 200-6550 Post, Cabinet Rear
11 200-1953 Brace, Front Cabinet
12 200-6507 Support, Cross Cabinet
13 810-1105 Magnet, Door
14 Manifold, Rear (not present in single fryers)
823-3223 Two-Station
823-4691 Three-Station
823-4693 Four-Station
823-4694 Five-Station
15 823-4653 Channel, Side Base
16 Channel, Front Base
200-6616 Single Fryer (also used as rear base channel in single-station fryers)
200-6623 Two-Station (also used as rear base channel in single-station fryers)
200-6624 Three-Station (also used as rear base channel in single-station fryers)
200-6625 Four-Station
200-6627 Five-Station
17 Channel, Rear Base
200-6626 Four-Station
200-6628 Five-Station
18 823-4732 Hinge, Lower Left
19 823-4733 Hinge, Lower Right (attach to bracket 200-5478 in 3-, 4-, & 5-station fryers)
20 810-0944 Caster w/Brake, 8 1/2 to 10-inch Adjustable (3-inch wheel)
21 810-0327 Caster w/o Brake, 8 1/2 to 10-inch Adjustable (4-inch wheel)
22 809-0953 Bolt, 1/4-20 x 3/4-inch Hex Head
23 809-0191 Washer, 1/4-inch Lock
24 809-0417 Nut, 1/4-20 Flange
