2-21
ITEM PART # COMPONENT
1 Valve Assembly, Microswitch and Ball Valve
106-3452 Valve, Rear Flush Assembly, Left Side
106-3453 Valve, Rear Flush Assembly, Right Side
2 810-2493 Elbow, 90º x ¼-inch NPT x ¼-inch Tube
3 809-0601 Clip, Rod End Clevis
4 Shaft, Rear Flush Valve
211-6701 For use in Left oil return valve assemblies
212-6701 For use in Right oil return valve assemblies
5 Handle, Rear Flush Valve
901-2772 For use in Left oil return valve assemblies
902-2772 For use in Right oil return valve assemblies
6 813-0165 Elbow, 90 º x ½-inch Street
7 813-0087 Nipple, 1 ½-inch BM NPT
8 810-2201 Valve, ½-inch Ball
* 900-2935 Oil Return Valve Nut Retainer
9 810-1668 Adapter, ⅝-inch Flexline to ½-inch NPT Male
9a 810-2786 Adaptor, ½ -inch Flare x ½ -inch NPT
10 807-2484 Valve, ¼-inch NPT Solenoid Vent
11 Manifold Rear Flush Oil Return
810-2890 Two-Station Fryer
810-2891 Three-Station Fryer
810-2892 Four-Station Fryer
810-2893 Five-Station Fryer
12 813-0156 Cap, ½-inch Pipe
13 816-0220 Insulation, Rear Flush Switch
14 807-4101 Microswitch, Lever Activated
15 826-1366 Nut, 4-40 Keps Hex (Pkg. of 25)
16 826-1359 Screw, 4-40 x ¾-inch Slotted Round Head (Pkg. of 25)
17 809-0250 Nut, 6-32 Keps Hex
18 200-8745 Cover, Microswitch Rear Flush
19 807-0125 Bushing, .50 ID Heyco SB-750-8 Nylon
20 813-0700 Nipple, ¼-inch NPT x 3-inch
21 816-0643 Grip, Oil Return Handle
22 810-1067 Flexline,
⅝-inch OD x 8.5-inch Oil Return
23 810-2787 Flexline, ½-inch x 5-inch Oil Return Manifold to Pump
24 810-1055 Flexline,
⅝-inch OD x 11½-inch Oil Return Manifold to Pump
25 811-1071 Tube, ¼-inch OD Teflon Manifold Vent
