2-29
ITEM PART # COMPONENT
1 106-1019SP Flue Assembly, Full-vat
2 200-0936 Back, Left Full-vat Combustion Chamber
3 200-0937 Back, Right Full-vat Combustion Chamber
4 200-2227 Retainer, Full-vat Upper Insulation
5 809-0059 Nut, 1/4-20 Flange Hex
6 809-0361 Screw, #8 X 1/2-inch Hex Head Drill Point
7 809-0362 Screw, #8 X 1 1/4-inch Hex Washer Head Drill Point
8 809-0435 Washer, Steel
9 809-0500 Screw, #10 X 1/2-inch Hex Washer Head 410 SS
10 809-0804 Nut, 1/4-20 Keps Hex
11 810-0476 Spacer, .25-inch X 1.187-inch
12 810-0500 Spacer, .25-inch X .9375-inch
13 826-1072 Burner, Universal Replacement
14 812-0355 Insulation, Full-vat Lower Rear
15 812-0356 Insulation, Burner Sight Glass
16 816-0577 Insulation, Burner
17 812-0404 Insulation, Left or Right Front Seal
18 812-0457 Insulation, Full-vat Lower Front
19 812-0706 Insulation, Upper Burner Rail
20 812-0993 Insulation, Upper Oil Zone
21 812-1029 Insulation, Combustion Chamber Side
22 814-0048SP Glass, Burner Sight
23 816-0057 Gasket, Plenum
24 816-0560 Insulation, Full-vat Upper Front
25 816-0561 Insulation, Left or Right Outer Front
26 823-0969 Plenum, Full-vat
27 823-1777 Side and Rail, Left Full-vat Combustion Chamber
28 900-4253 Strip, Fluecap Retainer
29 823-3142 Side and Rail, Right Full-vat Combustion Chamber
30 823-3304 Front, Full-vat Right Combustion Chamber
31 823-3305 Front, Full-vat Left Combustion Chamber
32 823-3315 Retainer, Left Full-vat Lower Front Insulation
33 823-3316 Retainer, Right Full-vat Lower Front Insulation
34 824-0863 Retainer, Left Full-vat Upper Insulation
35 824-0864 Retainer, Right Full-vat Upper Insulation
36 900-1031 Retainer, Burner Sight Glass
37 900-1049 Retainer, Plenum Gasket
38 900-1221 Retainer, Rear Insulation
39 900-1515 Brace, Upper Oil Zone Insulation
40 900-4452 Retainer, Combustion Chamber Side Insulation
41 930-0818 Bracket, Flue to Frypot
* 910-2474 Pot-to-Pot Gap Clip
* 826-0929 Insulation Kit, Complete Full-Vat
* 826-0931 Insulation Kit, Burner Full-Vat
* 106-1050SP Frypot, Complete Assembly, Natural/Propane
* 106-1053 Frypot, Complete Assembly, Manufactured Gas
* Not illustrated.
