2-7
ITEM PART # COMPONENT
1 Frame, Control Panel
106-3902SP Two-Station, Standard (use 106-5221SP mfd. After 3.15.06) (use 106-6082 for fallback)
106-3903SP Three-Station, Standard (use 106-5018SP mfd. After 3.15.06) (use 106-6086 for fallback)
106-3904SP Four-Station, Standard (use 106-5019 mfd. After 3.15.06) (use 106-6087 for fallback)
106-3905 Five-Station, Standard (use 106-5020 mfd. After 3.15.06) (use 106-6089 for fallback)
2 210-5819 Bezel, Two-Controller
3 210-6698 Bezel, Three-Controller
4 210-5046 Bezel, One-Controller
5 210-5623 Bezel, Blank
6 Brace, Cabinet Top
900-7730 Two-Station
900-9430 Three-Station
900-9318 Four-Station
200-5474 Five-Station
7 200-5478 Divider, Cabinet
8 200-6614 Post, Cabinet Front
9 200-6031 Post, Filter Door
10 200-2235 Bracket, Component Box Support
11 200-6550 Post, Cabinet Rear
12 200-1953 Brace, Front Cabinet
13 200-6507 Support, Cross Cabinet
14 810-1105 Magnet, Door
15 Manifold, Rear
823-3223 Two-Station
823-4691 Three-Station
823-4693 Four-Station
823-4694 Five-Station
16 200-2213 Bracket, Rear Bridge Support
17 200-0913 Bridge, Filter Pump
18 200-6326 Gusset, Left Rear Corner
19 200-7031 Gusset, Right Rear Corner
20 201-6508 Support, Left Filter Rail
21 202-6508 Support, Right Filter Rail
22 823-4651 Slide, Filter Pan Lid Left
23 823-4652 Slide, Filter Pan Lid Right
24 200-2102 Brace, Side Channel
25 823-4653 Channel, Side Base
26 Channel, Front Base (not used in two-station fryers)
200-6609 Three-Station
200-6610 Four-Station
200-5473 Five-Station
27 Channel, Rear Base
823-4510 Two-Station
823-4630 Three-Station
823-4629 Four-Station
823-4628 Five-Station
28 823-4732 Hinge, Lower Left
29 823-4733 Hinge, Lower Right (attach to hinge bracket 200-5478 in 4- & 5-station fryers)
30 810-0944 Caster w/Brake, 8 1/2 to 10-inch Adjustable (3-inch wheel)
31 810-0327 Caster w/o Brake, 8 1/2 to 10-inch Adjustable (4-inch wheel)
32 809-0953 Bolt, 1/4-20 x 3/4-inch Hex Head
33 809-0191 Washer, 1/4-inch Lock
34 809-0417 Nut, 1/4-20 Flange
* 810-1494 Caster w/o Brake, 4-inch Swivel
* 810-0326 Caster w/Brake, 4-inch Adjustable
* Not illustrated.
