Follett MCC400A/W - Manual (Page 6)

527mm (20.75")
578mm (22.75")
331mm
(13.00")
124mm
(4.875")
61mm
(2.375")
175mm
(6.875")
51mm
(2")
48mm (1.875")
178mm (7.00")
A
A
B
B
F
F
D
E
C
A
B
C
C
432mm
(17.00")
527mm (20.75")
432mm
(17.00")
L U L U R R NSF NSF
Front view — air-cooled
Satellite-fill
Side view — air-cooled
Satellite-fill
Top back view — air-cooled
top mount
Front view — water-cooled Side view — water-cooled
327mm
(12.875")
121mm
(4.75")
213mm
(8.375")
57mm
(2.25")
48mm (1.875")
6
Dimensions and clearances
Entire front of icemaker must be clear of
obstructions/connections to allow removal.
305mm (12") clearance above icemaker for service.
153mm (6") minimum clearance between exhaust
side of icemaker and any adjacent equipment.
MCC400A & C/ER400A – 457mm (18") minimum,
3m (10 ft) maximum clearance between discharge
and air intake grilles.
A – 3/4" MPT drain
B – 3/8" OD push-in water inlet
C – Electrical cord
D – 3/8" FPT condenser inlet
E – 3/8" MPT condenser drain
F – Bin signal cord
