84 • Network Tools
Genie Monochrome Series-GigE Vision Camera
Status Window Description
User Name
User assigned identification
Manufacturer
Manufacturer for this device
Model
GigE Vision device model
Serial Number
Device serial number
Firm Ver
Device firmware revision number
MAC adddress
Device MAC address
Camera IP
Device current IP address
NIC IP
NIC IP associated with the GigE server
Filter driver
Network driver status
MaxPktSize
Largest packet size that should be used for image streaming.
This is found using the Test Packet mechanism of GigE Vision.
ABI
Sapera Application Binary Interface to communicate with the device
Status
General device status
Note that the user can resize columns or drag any column header to reorder the displayed
information. Column order is automatically saved in an .ini file when the Genie Framework is
uninstalled and reinstalled.
Creating a Status Report
Before contacting DALSA technical support, the user should review the Troubleshooting section of this manual
(see
"
). Most installation, configuration, and imaging issues are documented along
with their solutions.
To aid technical support, the tool can save a network configuration report. From the File menu select “Save current
status”. You will be prompted for a filename for the report text file. This file should always be sent with any request
for technical support.
