32 • Operational Reference
Genie Monochrome Series-GigE Vision Camera
Read Only Parameters
Parameter
Description
Device Vendor
For the Genie Monochrome series, this is always DALSA.
Device Model Name
Displays the device model name (for example, Genie M640).
Device Version
Displays the device version.
Firmware Version
Displays the currently loaded firmware version.
Device ID
Displays the camera serial number.
MAC Address
Displays the unique MAC (Media Access Control) address of the Genie camera.
User Set Parameters
Parameter
Description
Device User ID
Specifies a user written ID, of up to 15 characters, for the Genie camera.
By default, this field is set to the serial number of the camera.
Power-up Configuration
Click Setting to open the Power-up configuration dialog box which allows you to specify
camera power-up configuration. For more information, see
" on page
32
.
Power-up Configuration
The Power-up configuration dialog allows you to specify the camera configuration to load when powering-up the
camera. The Genie camera flash memory contains two possible configuration settings; the Factory Default, and a
user-defined Camera Configuration 1. The Camera Power-up configuration drop-down list box allows you to
select either the Factory Default or a user specified camera configuration file. To save the current CamExpert
settings to the camera user-defined (Camera Configuration) setting, click Save. To view in CamExpert a camera
configuration file currently saved in the camera, select the configuration file in the Load configuration from
Camera drop-down list, and click Load. See
for a list of the saved
parameters.
