104 • Troubleshooting Genie Monochrome Series-GigE Vision Camera
GigE Server Warning Example 1b: IP error with multiple NICs
As a second example, the screenshot below shows an IP conflict error similar to the example above but the second
NIC has no camera connected (or only an Ethernet switch).
• The following illustration shows an example of this fault condition. The second NIC has not Genie connected
ether directly or via a switch.
Ho
st C
omp
ute
r
NIC 1
NIC 2
LLA Mode (only 1 NIC)
LLA Mode (error)
Persistence Mode - OK
Ethernet
Switch
• The solution again is that the second NIC must use the persistent IP mode or must have a DHCP server on that
subnet.
• For more information see " Multiple Camera Issues " on page 113 , " Using Genie with Ethernet Switches " on
page 17 , and " IP Configuration Mode Details " on page 77 .
