3.8
Primary, Secondary Unit (C-link)
The C-link feature, available when several GP-7000 series units are interconnected via NMEA
ports or PC/NMEA IN ports (see the illustration below), lets you duplicate on secondary stations
the destination set at the primary station. With this feature active destination may only be set from
the primary station.
1. Press the [MENU] key to show the menu bar.
2. Rotate the [ENTER] knob to choose ADVANCED from the menu bar and then push the
[ENTER] knob.
3. Rotate the [ENTER] knob to choose INPUT/OUTPUT and then push the [ENTER] knob.
4. Rotate the [ENTER] knob to choose C-LINK and then push the [ENTER] knob.
5. Choose Off, Secondary Station, Primary Station as appropriate and then push the [ENTER]
knob.
6. Press the [MENU] key to close the menu.
GP-7000
series
NMEA1
PC/NMEA IN
NMEA2
GP-7000
series
NMEA1
PC/NMEA IN
NMEA2
GP-7000
series
NMEA1
PC/NMEA IN
NMEA2
GP-7000
series
NMEA1
PC/NMEA IN
NMEA2
Primary station
Secondary station
Secondary station
Secondary station
Note: Secondary stations cannot
be connected to one another.
*
*
**
**
*: Either port
**: Either port
Secondary Station
Primary Station
Off
