29
Output
1) Rotate the [ENTER] knob to choose appropriate option and then push the [ENTER] knob.
2) Rotate the [ENTER] knob to choose Off or On as appropriate and then push the [ENTER]
knob followed by
W
.
6. Repeat step 5 to set up other ports.
7. Press the [MENU] key to close all open windows and erase the menu bar.
I/O format
Input data, sentence priority
Port
I/O format
Data sentence
Remarks
Input
NMEA 1, NMEA 2
IEC-61162-1,
NMEA-0183
Ver. 1.5/2.0/3.0
See table below.
PC/NMEA IN
RS232, and IEC
and NMEA above
For NMEA IN, see
table below.
Output
NMEA 1, NMEA 2
IEC-61162-1,
NMEA-0183
Ver. 1.5/2.0/3.0
GLL, VTG, BWR, DBT,
DPT, MTW, VHW,
WCV, APA, APB,
HDG, BOD, XTE,
RMA, RMB, RMC,
GGA, HSC, WPL,
RTE, TLL OUT, AAM,
GTD, MWV, ZDA
BWR: Rhumb line
PC/NMEA IN
RS232
Data
Sentence priority order
Remarks
Speed thru water
VHW
True heading
HDT, HDG, HDM
Magnetic heading
HDT, HDG, HDM
Target position
TLL
Radiotelephone target position
DSC, DSE
Waypoint data
RMB
Depth
DPT, DBT
Water temperature
MTW
Wind current, speed
MWV
Off
On
