GP-1610CF
Color GPS Plotter Sounder
The purpose of this Operator's Guide is to provide the basic operating procedures for this equip-
ment. For more detailed information see the operator's manual.
Course bar
01
PLOTTER
DISPLAY SOUNDER
DISPLAY
Fish school
Bottom
Position-fixing mode
Time
Position
CSE 350.0
°
SPD 16.8kt 2D
DEP 110 m TMP 1 6 . 0
°
C 13:42
POS 34
°
26.345’N 135
°
41.232’E
50k
0
50
100
150
200
Sounder frequency
Ship’s track
Waypoint
(Marks important
point (buoy, etc.);
can be set as
destination.)
Mark
(Marks point
of interest,
reef, etc.)
Chart
(Requires chart
card.)
Depth
Course
Water temperature
(Requires sensor.)
Speed
Depth scale
(Shown here
in meters.)
Own ship mark
(Shows current
position.)
Sample plotter/sounder display
The GP-1610CF is a fully integrated color video sounder, color video plotter and GPS receiver.
To find position, simply turn on the power. As your boat moves its track is inscribed on the
display.
