ii
SYSTEM CONFIGURATION
: Standard
: Option
GPS/VHF
combined antenna
GVA-100
GPS antenna
GSC-001
GPA-017S
Distributor unit
DB-1
VHF antenna
Power supply
PR-240
100-115/
200-230 VAC
1
φ, 50/60Hz 12-24 VDC
: Local supply
Either
24 VDC
MONITOR UNIT
FA-1502
12-24 VDC
UAIS TRANSPONDER
FA-1501
External display, NAVNET2, Pilot plug unit
Sensor
PC, BEACON RECEIVER
Alarm system
UNIVERSAL AIS
STATUS NAV
FA-150 PWR
DISP DIM
MENU ENT
LAN
Category of the units
GSC-001 Exposed to the weather
GPA-017S Exposed to the weather
GVA-100 Exposed to the weather
FA-1501 Protected from the weather
FA-1502 Protected from the weather
DB-1 Protected from the weather
PR-240 Protected from the weather
