Furuno FA-150 User Manual
Page 13
7
Stanchion
The
top of the stanchion comes
into
contact with the flange.
Installing distributor unit DB-1
The length of the cable between the distributor unit and transponder unit is 1 m so
locate the distributor unit within 1 m from the transponder unit. Fix the distributor
unit on the bulkhead, facing the cable entrance downward. Remove the lid of the
distributor unit and secure the unit with two self-tapping screws.
Self-tapping
screw
(4x30)
Note
: Be sure no foreign material or water enters the distributor unit.
