Fisher & Paykel DD90SDF(H)TX2 - Manual (Page 23)

23
THERE ARE TWO DIFFERENT PLUMBING AND DRAINAGE OPTIONS. CHOOSE WHICH IS MORE SUITABLE. 22
1
3
2
750-882.5 mm
1
2 38 mm
max.
120
mm
750-882.5 mm
* *
3 4
5
If space is limited
for fixing, push
hose through drain
hose support
to required height
If space is limited
for fixing, push
hose through drain
hose support
to required height
Dishwasher using sink trap with drain hose joiner
750 - 882.5 mm 750 - 882.5 mm
min. R 200 mm min. R 200 mm
Supplied drain hose joiner
19 mm waste tee
HIGHL
OOP
min. 150 mm
Ensure drain hose is routed straight
to joiner. Remove excess drain hose
material if necessary.
Do not shorten the inlet hose.
Dishwasher and Standpipe Ø 38 mm
Ensure the
supplied
rubber
washer
is fitted
inside the
coupling.
Important!
Do not connect the
drain hose to a waste
disposal unit, as this
type of connection may
lead to a blockage in
the drain hose.
Tighten coupling with spanner.
180 o No leaks!
CONNECT INLET HOSE TO COLD WATER PLUG PRODUCT IN 23 24
1 2
23 23 see see
