System configurator and order-information guide
D PRIMERGY R450 Status 2003-10-24
Section VIII Disk Array
D. 0-channel Ultra RAID Controller
The following cabling is standard, if any Disk Array Controller is used
1. Channel A of the RAID Controller is connected to the 1st backplane for 3 HDs
2. Channel B of the RAID Controller is connected to the 2nd backplane for 3 HDs
S26361-F2728-E48 zero-channel RAID Controller Adaptec 2000S
Zero-channel RAID Controller is always to be installed in slot 6
Adaptec
2000 S
48MB SDRAM ECC Cache
in combination with on-board
U160 SCSI Controller
without cable S26361-F2569-E64
incl. SW and description (Ger/US) 2-channel RAID Controller U160
64/66 PCI Controller Mylex / LSI
3.3V signaling AcceleRAID 352 (Leopard)
max. 1x per system 64MB SDRAM ECC Cache
BBU optional
Connector: internal 2x HD68;
S26361-F2385-E32 The cables for the connection of the external: 2x VHDCI
2-channel RAID Controller U160 RAID Controller to the disks in the system without cable
Adaptec are included within the basic unit. incl. SW and description (Ger/US)
3200 S 64/33 PCI Controller, 330mm
32MB SDRAM ECC Cache The cables of the connection from the 3.3V and 5V tolerant signaling
BBU optional subsystems (SX30 / S60) to the RAID max. 4x per system
connector: int. 2x HD68; Controllers, see configurator SX30 / S60
ext. 2x VHDCI
without cable S26361-F2569-E10
incl. SW and description (Ger/US) RAID Ctrl, Battery Backup Unit 4x
64/33 PCI Controller, 330mm max. 1x per Controller
3.3V and 5V tolerant signaling
max. 4x per system
S26361-F2386-E32 S26361-F2190-E128
RAID Ctrl, Cache Upgrade 32MB 4-channel RAID Controller U160
32 MB SDRAM ECC Cache Mylex / LSI
max. 1x per Controller eXtremeRAID 2000 (Big Apple)
128MB SDRAM ECC Cache
BBU
S26361-F2386-E10 connector: internal: 2x HD 68;
RAID Ctrl, Battery Backup Unit external: 4x VHDCI
max. 1x per Controller incl. SW and description (G/USA)
4x 64/33 PCI Controller, 330 mm
3.3V and 5V tolerant signaling
as soon as available max. 4x per system
S26361-F2752-E128
2-channel RAID Controller U320
Adaptec
2200S
128MB SDRAM ECC Cache
BBU optional
plug: internal 2x HD68;
external: 2x VHDCI
without cable
incl. SW and description (Ger/US)
64/66 PCI controller, 180mm
3.3V and 5V tolerant signaling
Max. 8 controllers max. 4x per system
in basic unit
to be continued S26361-F2752-E10
on previous page Cache Battery Backup Unit
max. 1x per controller
The fitting connection cables can be found in the
configurator "external storage systems"
E
Fujitsu Siemens Computers
Enterprise Products - PRIMERGY Server 9 of 12
