System configurator and order-information guide

PRIMERGY R450 Status 2003-10-24

Section

VII

SCSI-/Fibre-channel controller

A. on-board SCSI Controller for internal hard disks

2-channel U160-SCSI controller on-board; included as standard

The following cabling is standard, if no Disk Array Controller is used

1. Channel A of the U160 controller is connected to the 1st backplane for 3 HDs

2. Channel B of the U160 controller is connected to the 2nd backplane for 3 HDs

S26361-F2287-E15

This interface is only configurable if a RAID Controller

External on-board SCSI Interface

besides the 0-channel RAID Controller is used

Cable and external

See section Disk Array Controlller

connector interface

max. 2x per system for external

B. SCSI - controller for external hard disk extensions and external peripheral devices.

while stocks last

SNP:SY-F1722E1-P

S26361-F2399-E1

Controller for the connection of a EMC

SCSI Controller UW, DE

SCSI U160 Controller

Symmetrix (only available as option)

Adaptec 2944UW (HBA)

Adaptec SCSI card 29160

Supported only in Microsoft Windows

1 channel differential-ended

1 channel: LVD+Fast/Ultra (decoup.)

NT and Windows 2000 operating

max. 40MB/s; without cable

LVD con. for HD, withoud cable

systems

32/33 PCI, min. 170mm

Fast/Ultra con. access. drives

int: LD50 + HD68, ext: HD68(S)

64/66 (32/33) PCI, min. 180mm

SW:

int: Fast 50-pin or Ultra HD68

max. 2x per system

+ LVD HD68; ext: HD68(LVD)

SW:

max. 2x per system

C. Fibre Channel controller for subsystems and SAN

while stocks last

SNP:SY-F2244E1-P

SNP:SY-F2244E2-P

1GBit/s FC Controller

Qlogic

QLA 2200

QLA 2200F, full height braket

1 Channel 1GBit/sec FC Controller

CU (copper) Interface

MMF(Multimode Fibre) Interface

incl. SW and description (Ger/US)

PCI 64Bit / 66MHz, 175mm

3.3V and 5V tolerant signaling

max. 4x per system

while stocks last

S26361-F2843-E1

S26361-F2624-E1

suitable for

2GBit/s FC Controller

64Bit/66MHz

Emulex

PCI-Slot

LP9802

LP9002L

1 Cannel 2GBit/sec FC Controller

1 Channel 2GBit/sec FC Controller

Attention

LC Interface for 50um Fiber

LC Interface for 50um Fibre

2GBit/s FC Controller

PCI 64Bit / 133MHz, 170mm

PCI 64Bit / 66MHz, 170mm

require other interface

3.3V and 5V tolerant signaling

connectors for the

max. 4x per system

optical cables than

freigegeben

1GBit/s fibre channel.

SNP:SY-F1826L1-P

Supported only in Microsoft

FC Ctrl for EMC2 Attachment

Windows NT and

Emulex LP8000

Windows 2000 operating

There are other components

1 channel 100MB/s

systems.

such as switches, GBICs

MMF (Multimode Fibre) Interface

or cables which can be

Connector: Duplex SC

Controller for the connection

ordered for fibre channel SAN

without cable, order seperately

of a EMC Symmetrix, FibreCAT

attachments. (see price list)

incl. SW a. description (Ger/US)

(only available as option)

PCI 64Bit/33MHz controller

max. 4x per system

All controllers for the connection of external storage systems are delivered without cables

to be continued

For the configuration of external cabling see the configurator for external storage systems

on next page
